TECHNICAL SPECIFICATIONS

MOVEMENT

The PAM692 watch, the Panerai Luminor Submersible 1950 3 Days Automatic Bmg-tech, The automatic P.9010 calibre, entirely developed and created in the Panerai Manufacture in Neuchâtel, has central hour and minute hands, the small seconds dial at 9 o’clock and the date at 3 o’clock. The energy necessary to accumulate a power reserve of three days – the basic standard for Panerai in-house movements – is stored in two spring barrels whose springs are wound by an oscillating weight operating in both directions. Consisting of 200 components including 31 jewels, the calibre has a diameter of 13¾ lignes and it is 6 mm thick. The balance, fixed by a bridge with twin supports, oscillates at a frequency of 28,800 vibrations per hour (4 Hz). It is associated with the device which stops it as soon as the winding crown is pulled out, enabling the watch to be perfectly synchronised with a reference signal. In the P.9010 calibre the hours can be conveniently adjusted without interfering with the movement of the minute hand, thanks to the device which directly moves only the relative hand in jumps of one hour forward or backwards. This function is very useful when changing time zones or moving between summer time and winter time, and conveniently the adjustment of the hour hand is automatically connected to the date indicator. lugs for easy strap changes.

THE BASICS

The PAM692, is a Panerai Luminor Submersible 1950 model that was introduced in 2017. A key feature of this watch is the use of BMG-TECH (Bulk Metallic Glass) material for its case, bezel, crown, and crown protection device. This material is known for its strength, scratch resistance, and corrosion resistance

CASE
47 mm

HEIGHT
15 mm

GLASS
Sapphire

POWER RESERVE
3 Days

STRAP
Rubber
